Home : Signal Processing Systems : Aurora Multimedia Corp. - VLX-TCW2H-C-W
Aurora Multimedia Corp. - VLX-TCW2H-C-W
Request Quote
All Products
aurora-multimedia

AV over IP 4K 1Gbps Streaming Transceiver Wall Plate with 2-HDMI In, 1-HDMI Out, RS-232, IR, Audio, LAN, USB 2.0., White

Model: VLX-TCW2H-C-W

  • 4K visually lossless over 1Gbps network
  • Low 1.5 frame latency
  • HDMI® 2.0/HDCP 2.2
  • Unlimited scalability (based on network topology)
  • Videowall with image rotation
More Product Information Below
Compare
Project List
Product Info
Tech Specs
Documents

The VLX-TCW2H provides one of the most advanced IP Streaming solutions on the market utilizing Aurora's IPBaseT technology, which synergizes various IP/AV standards to work together as one. It is the industry's first 4K UHD transceiver with only 1.5 frame (25ms) latency and visually lossless compression. The VLX-TCW2H has 2 HDMI® ports. Using a transmitter (encoder) and receiver (decoder), respectively, used to be the standard – until now. The VLX-TCW2 Series can be set up as either one to make installation, inventory, and troubleshooting easier.

Note: The selected network switch needs to support:  1Gbps, Non-blocking IGMP & Jumbo Frame Packets.

  • 4K visually lossless over 1Gbps network
  • Low 1.5 frame latency
  • HDMI® 2.0/HDCP 2.2
  • Unlimited scalability (based on network topology)
  • Videowall with image rotation
  • PoE (Power over Ethernet)
  • Stereo line I/O
  • RS-232 and IR Control Ports
  • Auto sense switching
  • USB 2.0 Host and Device Ports
  • Dante® IP audio option
  • AV-over-IP - Yes
  • Spec Sheet available - Yes
  • Depth: 3.73 in
  • Height: 1.40 in
  • Width: 2.83 in
  • Product Weight: 2.50 lbs
  • Technical:
  • Compression: 8:1
  • Latency: 1.5 Frames (25ms)
  • HDMI Inputsa: 2 HDMI 2.0/HDCP2.2
  • HDMI Outputs: 1 HDMI 2.0/HDCP2.2
  • Audio Analog: Stereo Line In/Out (3.5mm TRS)
  • 1G Copper Ethernet: RJ-45
  • LAN: RJ-45 10/100/1000M PoE (PSE)
  • Video Bandwidth: 340MHz
  • Video Support: Up to 4K2K 4:2:0 @60Hz
  • Audio Support: Up to 32 channels & Break-away Capable
  • RS-232: 2 qty Up to 115k Baud (3.5mm TRS)
  • IR: Bi-Directional (3.5mm TRS)
  • USB Connector: 1 USB 2.0 Type A, 1 USB 2.0 Type B 2 USB 1.1 Type A
  • Expansion Port: Dante® Option
  • Interface: IR or Keypad via OSD, Webserver
  • Mechanical:
  • Housing: Aluminum
  • Mounting: Wall-mounting Decora® 2 Gang
  • Power Supply: 48V DC (2 pin Euro) or 1G PoE
  • Power Consumption: 9 Watts
  • Operation Temperature: 0~40C [32~104F]
  • Storage Temperature: -20~60C [-4~140F]
  • Relative Humidity: 20~90% RH [no condensation]
VLX-TCW2-Series-Spec-Sheet-1603281.pdf   749522 kb - Data Sheet
Aurora_IPBaseT_Brochure_2016_Web1.pdf   2352390 kb - Brochure
Catalog   7482941 kb - Other
